Technical description DM50
16
5.1 Description of the device
Front panel
Rear side
Control panel (inside the device)
No in
fig. 1, page 3
Description
1 Lock (optional)
2 Handle (DM50D only)
3 Door panel (DM50D only)
No in
fig. 2, page 3 and
fig. 3, page 4
Description
1 Mains adaptor
2 12 Vg socket
3 Cooling unit cover
4 Ventillation openings
5 Drip tray
No in
fig. 4, page 4
Description
1 Lamp
2 Error LED
3 Power Status LED
4 Setting button
