DM50 Installation
17
Main drawer
Mini drawer
6 Installation
6.1 Notes on mounting into furniture
You can mount the minibar in four ways into furniture. Choose your favoured
alternative according to fig. 7, page 6.
Observe the following:
The cut-out dimensions H x W x D are:
– DM50D: 428 x 570 x 485 mm
– DM50F: 428 x 570 x (485 + d) mm
d is the thickness of the hotel‘s own decor
The clearance between the minibar‘s back and the furniture wall should
be approx. 5 mm.
The ventilation openings for the chosen alternative have to be produced
as shown in fig. 7 , page 6.
Air passing through the inlet air duct must not be heated by any heat
sources (heaters, direct sunlight, gas ovens etc.).
No in
fig. 5, page 5
Description
1 Wide divider
2 Separator
3 Small divider
4 Bottle finger
No in
fig. 6, page 5
Description
1 Rotatable divider
2 Miniature bottle holder
