Installation DM50
18
6.2 Pressing out the ventilation opening
fig. 9, page 7
➤ Produce a ventilation opening of 30 x 300 mm in the bottom of the
furniture into which you place the minibar.
Measure the distance of 470 mm from the minibar‘s door front excluding
any own decor.
6.3 Mounting the minibar into a piece of furniture
➤ Fasten the minibar with the four screws ø4 x 45 mm (fig. 0 1, page 7).
➤ Insert the four plugs (fig. 0 2, page 7) into the boring.
➤ Fasten the inlet filter (fig. 0 5, page 7) with the six screws ø3 x 12 mm
(fig. 0 6, page 7) to ventilation opening (fig. 0 4, page 7) of the furni-
ture (fig. 0 3, page 7).
6.4 Connecting the minibar electrically
➤ Plug the 230 V connection cable into the AC voltage socket and connect
it to the 230 V AC mains supply.
✓ The Power Status LED lights up.
✓ The lamp lights up and the minibar starts cooling the interior.
No in
fig. 0, page 7
Description
1 Screw ø4 x 45 mm
2Plug
3Furniture
4 Ventilation opening
5Filter
6 Screw ø3 x 12 mm
