Continuous drainage
If you do not want to drain water in the water tank frequently, you can
c
Two kind of pipe is optional . One is inner diameter 9mm ,which provided by
manufacturer. Another is standard screw thread garden drain pipe with outer
diameter of 1 1/16 inches and the pitch of 11.5TPI
onnect a drainage pipe on the back of this
dehumidifier to drain water.
Find the position where the
water outlet is blocked on the
back, as shown in figurebelow:
Pull down the water plug and
connect drain pipe like following
figure 1(provided pipe connect) or
figure 2(garden drain pipe connect).
Attention: the level height of externally connected water pipe shall not be higher
than the water outlet, and the water pipe at rear-end shall transit smoothly,
otherwise, the leakage risk exists since drainage is not smooth.
