Installation
Please drain the water from water tank be fore running.
During running please do not open doors and windows as much as
possible since this can save energy resources.
When the dehumidifier is installed, a certain space must be reserved
around this dehumidifier, t he minimum distance above is 19.7in. and
the minimum distance in front/rear and left/right is 7.9in. as
required, as shown in figure below.
When bi g noise is found during operation of this dehumidifier:
It is recommended inserting pads or damping rubber sheets, etc.
below this dehumidifier, this can reduce vibration and noise, and can
also reduce s inking of wood floor or carpet.
at least 19.7in.
at least 7.9in.
at least 7.9in.
at least 7.9in.
at least 7.9in.
