Dometic HBH2000L User Manual

ENGLISH
12
SYMBOLS
WARNINGS AND SAFETY SYMBOLS
The safety symbols utilised identify possible hazards to users.
Always respect all safety warnings identified with these symbols:
INDEX
INSTALLATION 13
SAFETY WARNINGS 13
CABINET APERTURE 13
CONNECTING TO GAS SUPPLY 14
WIRING- CONNECTING TO ELECTRICITY SUPPLY 15
FIXTURE 15
USE 16
WARNINGS 16
CONTROLS 16
BURNERS: 17
HOB: 17
SELECTING BURNER 17
ELECTRONIC IGNITION HOB (DEPENDING ON MODEL) 17
MANUAL IGNITION HOB 18
HOB FLAME REGULATION 18
VISUAL FLAME CONTROL 18
GAS CYLINDERS / BOTTLES 19
MAINTENANCE 20
CLEANING 20
INJECTORS 20
FIGURES AND TECHNICAL DRAWINGS 122-125
WARNING
Hazard of injury or death.
CAUTION
To prevent possible injury
and / or damage
INSTALLATION
USEMAINTENANCE
INSTALLATION
ENGLISH
13
SAFETY WARNINGS
WARNING: THIS WARNING IS AFFIXED TO THE APPLIANCE. THIS
APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH REGULATIONS IN
FORCE AND ONLY USED IN AN ADEQUATELY VENTILATED AREA. ALWAYS
READ THE INSTRUCTIONS PROVIDED IN FULL BEFORE INSTALLING
AND USING THIS APPLIANCE. THIS APPLIANCE MUST BE INSTALLED BY
SPECIALIST GAS SERVICE ENGINEERS.
THIS APPLIANCE IS DESIGNED AND MANUFACTURED FOR COOKING
FOOD ONLY. ANY OTHER USE IS CONSIDERED IMPROPER AND INCORRECT
CREATING HAZARDOUS CONDITIONS. THE MANUFACTURER DECLINES
ALL RESPONSIBILITY FOR DAMAGE TO THINGS OR INJURIES TO PERSONS
CAUSED BY INCORRECT INSTALLATION AND / OR INCORRECT AND
IMPROPER USE.
BEFORE INSTALLING CHECK THAT THE LOCAL GAS AVAILABLE (GAS TYPE
AND PRESSURE) AND THE APPLIANCE REGULATORS ARE COMPATIBLE WITH
THE APPLIANCE ITSELF.
GAS REGULATING SPECIFICATIONS FOR THIS APPLIANCE ARE PROVIDED ON
THE LABEL AFFIXED TO THE APPLIANCE (OR ON THE SERIAL PLATE).
THIS APPLIANCE IS NOT CONNECTED TO A FUME EXTRACTION FLUE
FOR EXTRACTING PRODUCTS OF COMBUSTION THEREFORE IT MUST BE
INSTALLED AND CONNECTED (FITTED) CONFORMING TO INSTALLATION
REGULATIONS IN FORCE FOR APPLIANCES OF THIS TYPE. IT IS OF UTMOST
IMPORTANCE TO RESPECT LEGISLATION REGARDING VENTILATION.
THE APPLIANCE MUST FITTED AT AN APPROPRIATE AND SAFE DISTANCE
FROM FLAMMABLE MATERIALS.
CABINET APERTURE
This hob has a class 3 grading: BUILT-IN APPLIANCE FOR KITCHENS OR WORKTOPS
MINIMUM ALLOWABLE DISTANCES FROM WALLS (FIG. 1 - PG. 122):
A / B FROM THE OUTER EDGE OF THE BURNER HEAD NEAREST ONE OF THE SIDE WALLS AND / OR
REAR WALL:
135 mm
C THE DISTANCE BETWEEN THE TOP OF THE BURNER AND THE BOTTOM OF THE UNITS AND /
OR SHELVES FITTED ABOVE THE HOB:
500 mm
D THE DISTANCE BETWEEN THE BOTTOM OF THE BURNER AND THE UNDERSIDE:
30 mm
SIZE OF CABINET APERTURE
Cut-out a hole in the cabinet as illustrated in FIG. 2 - PG. 123 depending on model to install.
The cabinet must be appropriately constructed and aligned horizontally with the worktop and with the unit.
The cabinet aperture must be perfectly squared and aligned.
If there are apertures for cabinet ventilation, prevent ammable materials from entering these.
DometicHBH2000L-R_IOM_4445103212_EMEA12_xxxx-xx-xx.indd 12DometicHBH2000L-R_IOM_4445103212_EMEA12_xxxx-xx-xx.indd 12 27.10.2020 16:22:4627.10.2020 16:22:46
