USEMAINTENANCE
INSTALLATION
This appliance is designed for running off the following types of gas at the corresponding operating pressures. The gas
category (or categories) of the appliance is given on the specications label afxed to the appliance.
CONNECTING TO GAS SUPPLY
CHECK THESE SPECIFICATIONS BEFORE CONNECTING THE APPLIANCE TO
THE GAS CYLINDER /BOTTLE. THE PRESSURE REGULATORS CONNECTED
BETWEEN THE GAS CYLINDER AND APPLIANCE MUST CONFORM WITH THE
CATEGORIES GIVEN IN THE TABLE BELOW.
The gas supply pipe connected to the appliance must be a rigid metal pipe with sealed ttings. It is possible to t a
exible hose, however, in this case the following conditions must be respected:
a) The hose can be accessed easily for inspection;
b) The hose must be protected against coming into contact with parts which heat up (for example parts
underneath the burners);
c) The hose must be protected against being damaged (twisting, pulling, trapping,….);
d) The hose must be protected against being trapped by moving parts (e.g. drawers);
e) The hose must not have a length over 1.5 m;
f) The hose must be replaced before its expiry date;
Once the appliance has been connected to the gas supply check for gas leaks utilising a non-corrosive uid.
Do not use a water and soap solution. NEVER USE A FLAME TO TEST FOR GAS LEAKS.
WHEN INSTALLING AND CONNECTING THE APPLIANCE TO THE GAS SUPPLY,
ENSURE THAT THE GAS SUPPLY HOSE IS NOT TWISTED, STRETCHED OR
SUBJECTED TO ANY FORM OF STRAIN WHICH COULD CREATE A HAZARD.
CATEGORY AND COUNTRY OF DESTINATION
I3B/P(30)
AT BE DE DK FI GB NL NO PT SE SI
I3+ (28-30/37)
BE CH ES FR GB IE IT PT SI
GAS PRESSURE
30 mbar Butane (G30)
30 mbar Propane (G31)
28-30 mbar Butano (G30)
37 mbar Propano (G31)
MODEL TOTAL NOMINAL THERMAL
CAPACITY
AIR VOLUME REQUIRED FOR
COMBUSTION
kW - gr/h m
3
/h
HBH2000L - HBH2000R
4,4 - 335 8,8
ENGLISH
14
MAINTENANCE USE
INSTALLATION
FIXTURE
THIS APPLIANCE MUST BE FITTED AND SECURED TO THE CABINET UTILISING THE FIXTURE SCREWS AS
ILLUSTRATED IN FIG. 3 - PG. 124.
CONNECTING TO ELECTRICITY SUPPLY
THIS APPLIANCE MUST BE CONNECTED TO A 12 V POWER PACK. THE
CIRCUIT MUST BE FITTED WITH A SAFETY FUSE NOT HIGHER THAN 3 AMP.
WHEN WIRING THE APPLIANCE RESPECT CORRECT POLARITY!
IT IS OF UTMOST IMPORTANCE NEVER TO CONNECT THIS APPLIANCE
TO MAINS VOLTAGE (230 V~) WHICH IRREVERSIBLY DAMAGES APPLIANCE
COMPONENTS AND CREATES A HAZARD TO THE USER.
To connect the appliance use a 1.5 mm
2
double red and black wire and wire to the terminal junction box located at the
rear of the appliance with the wording "+12 V – ". The red terminal is the positive pole and the black terminal is the
negative pole.
LOW VOLTAGE 12 V
This chapter refers only to models with the wording 12 V on the appliance specications label afxed to the
appliance.
ENGLISH
15
DometicHBH2000L-R_IOM_4445103212_EMEA12_xxxx-xx-xx.indd 15DometicHBH2000L-R_IOM_4445103212_EMEA12_xxxx-xx-xx.indd 15 27.10.2020 16:22:4727.10.2020 16:22:47
