Setting up and connecting the appliance MaCave
19
S17G and S46G can be mounted into a kitchen plinth beneath the kitchen
counter.
S24G, S118G and ST198D can be mounted into a kitchen cabinet .
S17G and S46G installation (fig. j, page 6)
➤ Check the dimensions (in mm):
➤ If using a plinth:
Ensure that the ventilation openings in the plinth have a cross-section of
at least 300 cm
2
.
S118G and ST198D installation
➤ Check the dimensions (in mm):
S24G installation (fig. k, page 7)
➤ Check the dimensions (in mm):
z Warmed air must be dissipated via a ventilation shaft at the rear side.
z The ventilation shaft must have a cross-section of at least 200 cm
2
.
z The plastic seals included are mounted to seal right and left between the
device and the kitchen unit.
Width Depth Height
S17G 300 min. 575 822 – 892
S46G 600 min. 575 822 – 892
Width Depth Height
S118G 600 min. 575 1815
ST198D 600 min. 575 1815
Width Depth Height
S24G 560 550 450
