Dometic MasterFlush MF 8140 - Components; Specifications

5
Dometic 8700 Series MasterFlush Toilet Intended use
5 Specifications
5.1 Materials
Toilet: vitreous ceramic
Macerator pump body: glass-lled polypropylene
Control module housing: ABS
Dometic switch panel frame: ABS
Dometic switch panel: polycarbonate resin
Flush handle: plated brass (on applicable toilet
models)
4 Components
(g.
1
, page 2)
Ref. Description
A Macerator toilet
B Dometic ush switch/status panel
C Control module
D 4-wire cable to toilet
E Cable from Dometic ush switch
(RJ45 ethernet cable)
F 6-wire cable to ush switch/
status panel
G Incoming electrical power wires
H Power wires to raw water pump (opt.)
I Wire from “full tank” signal
J Floor mounting hardware kit
K Floor mounting template
L Flush handle (alternate model)
M Dometic status panel
(for ush handle model only)
N Cable for ush handle, status panel
(for ush handle model only)
Ref. Description
1 Anti-siphon valve
2 Vacuum breaker
3 Discharge loop outlet
4 Discharge adapter tting
5 Discharge hose tting
6 Macerator pump
7 Water valve
8 Water line - 0.5 in. NPT tting
9 4-pin cable connector
10 Flush handle (alternate model)
11 Flush handle cable connector
Refer to complete parts list (packed separately)
for additional information.
(g.
2
, page 2)
