Rastrollo 3000 Fitting the blind
11
3 Fitting the blind
Marking the position of the cassette (fig. 2, page 3)
➤ Align the blind with the window cut-out and mark where the holes are to
be drilled for the cassette.
Selecting the fastening method (fig. 3, page 4)
I
NOTE
For cassettes wider than 1200 mm, prevent the blind from hanging
down by fixing the blind with the bracket to the wall (A) or with the
plate to the ceiling or a top cupboard (B) as well.
➤ Decide whether you want to fix the blind with the bracket to the wall (A) or
with the plate to the ceiling or a top cupboard (B).
➤ Insert the bracket or plate as follows:
– Bracket in the middle in the rear ventilation slot (A),
– Plate in the middle in the front ventilation slot (B).
The bracket or plate must click in.
Fastening the cassette (fig. 3, page 4 and fig. 4, page 4)
A
NOTICE!
If the screws supplied do not hold in the wall, you must use
plugs suitable for the wall construction.
Make sure you do not drill through the wall.
➤ Pre-drill at the marked points if the wall construction requires this.
➤ Fix the cassette with the screws to the wall (fig. 3, page 4).
➤ Fasten the bracket or plate as follows (fig. 4, page 4):
– Bracket with a screw to the wall (A),
– Plate with a screw to the ceiling or a top cupboard (B).
