RC(S)(L)(D)10-Series Technical description
23
RC10.4S.70, RC10.4S.90, RC10.4P.100, RC10.4M.90, RCL10.4(E)S,
RCD10.5(X)S, RCS10.5(X)S
The LED display features the following operating and display elements (fig. 1 B,
page 5):
Boost
• Thermostat settings fixed on maximum
• Compressor operates in high rpm mode
• External ventilation fan operates in high rpm mode
Settings (only RCD models):
Frame heater
Symbol lights up when the frame heater is operating.
The frame heater of the frozen compartment reduces con-
densation.
Symbol lights up when the refrigerator is connected to
the CI bus.
Symbol lights up when child lock is enabled:
• Push the rotary button 3 times within 1,5 seconds to
unlock the controls.
• After 10 seconds of inactivity the controls will lock
again automatically.
Beep off:
Error messages, warning messages and door left open for
an extended period are not signaled acoustically.
Beep on:
Error messages, warning messages and door left open for
an extended period are signaled acoustically.
Confirm selection and return to the main menu
Symbol Description
ON/OFF button
Performance mode
• All thermostat settings selectable
• Compressor operates in high rpm mode
• External ventilation fan operates in high rpm mode
Symbol Description
Settings
