RC(S)(L)(D)10-Series Using the refrigerator
29
To remove and insert the VG fresh base:
➤ Proceed as shown (fig. 7, page 10).
5.7 Positioning the shelves
!
1. Remove the shelf as shown (fig. 8, page 11).
2. Refit the shelf in the reverse order.
Positioning the shelf at an angle for wine bottles
A
➤ Change the position of the shelf as shown (fig. 9, page 11).
5.8 Removing the frozen compartment
Take out the frozen compartment to make more space in the refrigerator compart-
ment.
I
➤ Proceed as shown (fig. 0, page 12).
WARNING! Risk of child entrapment
All shelves are fixed in place to prevent children from climbing into the
refrigerator.
• Only remove the shelves for cleaning purposes.
• Refit the shelves and secure them in place.
NOTICE! Damage hazard
While driving, the shelf in the angled position must not be filled.
NOTE
• Keep the frozen compartment door and the base in a safe place to
prevent any damage.
• When installing, replace the parts in the reverse order.
