Dometic RM 5380 Installation Manual

EN
RM5310, RM5330, RM5380 Connecting the refrigerator
85
➤ Connect the refrigerator as shown in fig. t, page 11 (without lighting)
and fig. u, page 12 (with lighting):
230 Vw:
➤ Connect the refrigerator to a 230 Vw mains socket with the mains plug.
12 Vg:
Observe the following cable cross sections:
– < 6 m (in the interior): 4 mm
2
– > 6 m (in the interior): 6 mm
2
– Cables laid over the shaft (Caravan only): 2.5 mm
2
➤ Secure the power supply line for the heating element
(connection 3/4) with a 16 A fuse, and the power supply line for
the lighting (connection 5/6) with a 2 A fuse.
➤ Lay the power supply line for the heating element (connection 3/4) via a
ignition-controlled relay to prevent the battery from accidentally being
discharged completely when the engine is switched off (fig. s, page 10).
Item Description
1 Heating cartridge battery
2 Connection cable 12 Vg
3 Earth, battery, heating element
4 Positive, battery, heating element
5 Positive, lighting
6 Negative, lighting
7 Reed contact (sensor circuit)
8 Galvanometer
9 LED lighting, battery
10 Thermocurrent adapter
11 Heating cartridge, mains
12 Connection cable 230 Vw
13 On the housing

Dometic RM 5380 Specifications

General

Door hinge	Left
Product color	Black, Grey
Custom panel-ready	-
Appliance placement	Freestanding
Refrigerating medium	R717
Noise level	- dB
Climate class	SN
Total net capacity	75 L
Total gross capacity	80 L
Lamp type	LED
Fridge net capacity	70 L
Fridge interior light	Yes
Freezer position	Top-placed
Freezer net capacity	5 L
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	- kWh
Package depth	543 mm
Package width	523 mm
Package height	845 mm
Package weight	29000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	821 mm
Weight	24000 g
