RM5310, RM5330, RM5380 Changing the door hinge
81
➤ Fit the ventilation grille LS100 (9) in the installation frame (6) and lock it
in place.
➤ Push the covering cap (8) onto the exhaust gas pipe (7).
➤ Fit the insert for the exhaust gas routing (10) into the ventilation grille (9).
6.6 Fastening the refrigerator
!
I
➤ Place the refrigerator in its final position.
➤ Turn the four bolts through the four plastic bushings into the side walls of
the refrigerator (fig. d, page 7) and on into the wall of the recess.
7 Changing the door hinge
➤ Release the bolts on the door lock (fig. e, page 8) and remove the bolt,
the door lock and the spacer.
➤ Remove the bolt on the other side and keep it (fig. f, page 8).
➤ Lift the door and remove it (fig. g, page 8).
➤ Release the cap (fig. h, page 8) and replace it on the other side of the
door (fig. i, page 8).
➤ Unscrew the hinge pin (fig. j, page 8) and replace it on the other side
(fig. k, page 8).
➤ Place the door on the hinge pin (fig. l, page 8).
➤ Fasten the bolt to the upper door hinge (fig. m, page 9).
➤ Attach the door lock (fig. n, page 9).
CAUTION!
Always drill through the bushings provided, as foamed-in parts
such as cables etc. could be damaged otherwise.
NOTE
Fasten the side walls or attached bars in such a way that the bolts
are firm even under increased loads (while the vehicle is driving).
