Installing the refrigerator RM5310, RM5330, RM5380
80
6.4 Mounting the ventilation grilles
LS100
LS200
➤ Seal the installation frame in a water-proof manner (fig. 9, page 6).
➤ Fit the installation frame and bolt it tight (fig. 0, page 6).
➤ Fit the ventilation grille and lock it (fig. a, page 6).
Only for LS100
➤ Fit the insert for exhaust gas routing (fig. b, page 6).
6.5 Mounting the exhaust gas routing (fig. c, page 7)
➤ Plase the T-piece (1) on the adapter (2) and the exhaust gas pipe (3)
➤ Fix the T-piece, adapter and exhaust gas pipe in place with a bolt (4).
➤ Make sure that the heat distributor (5) is in the correct position.
➤ Push the exhaust gas pipe with the cover plate (7) through the opening in
the installation frame provided for that purpose (6).
➤ Connect the exhaust gas pipe and the cover plate with the T-piece (1).
➤ Shorten the exhaust gas pipe (7) to the right length if necessary.
No. in
fig. 7, page 5
Description
1 Installation frame
2 Ventilation grille
3 Insert for exhaust gas routing
4 Winter cover
No. in
fig. 8, page 6
Description
1 Installation frame
2 Ventilation grille
3 Winter cover

Dometic RM 5380 Specifications

General

Door hinge	Left
Product color	Black, Grey
Custom panel-ready	-
Appliance placement	Freestanding
Refrigerating medium	R717
Noise level	- dB
Climate class	SN
Total net capacity	75 L
Total gross capacity	80 L
Lamp type	LED
Fridge net capacity	70 L
Fridge interior light	Yes
Freezer position	Top-placed
Freezer net capacity	5 L
Current	0.54 A
Power source	Gas/Electric
Connected load	125 W
Gas consumption	270 g/24h
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	- kWh
Package depth	543 mm
Package width	523 mm
Package height	845 mm
Package weight	29000 g

Weight and Dimensions

Depth	474 mm
Width	486 mm
Height	821 mm
Weight	24000 g
