9
OPTION 4
Consists of Two Side Vents
Natural draft side ventiliation with the top side vent connected to the refrigerator flue. In minumum sized
enclosures it prevents the flue gases from raising the temperature at the rear of the refrigerator.
Note: See Pages 10 through 15 for approved Dometic refrigerator vent options.
Model
No.ABCDEF GH
RM4290 32 20-1/4 31-1/2 20-3/4 9-1/4 7-1/2 1 5
RM4292 32 20-1/4 31-1/2 20-3/4 9-1/4 7-1/2 1 5
Max.
Dim.
Min.
Dim.
Min.
Dim.
Min.
Dim.
Max.
Dim.
(Dimensions in Inches)
Max.
Dim.
VIEW FROM ABOVE
