RMDX21, RMDX25 Technical description
11
6.3 Control elements
The control elements for the refrigerator are found behind the lower refrigerator
door. The refrigerator features the following illuminated control elements:
No. in
fig. 3
Description
1 ON/OFF button
2 Operating with AC power supply
3 Gas operation
4 Operating with DC power supply
5 Automatic mode (RMDX25 only)
6 Setting the operating time of the freezer compartment
frame heater
7 Setting the temperature
8 Temperature indication
9 Malfunction indicator
Reset button for a gas malfunction
1 2 3 4 5 6 7 8 9
