RML10.4, RML10.4S, RML10.4T Connecting the refrigerator
23
Circuit diagram of the refrigerator (fig. j, page 10)
Item in
fig. j,
page 10
Description
1 Fan 2 (if options module is not available)
2 Fan 1 (if options module is not available)
3 S+ (optional)
4 Heating element DC
5 DC relay with 20 A fuse for heating cartridge
6 NTC 1: Refrigeration room
NTC 2: Outside temperature (optional)
7 Gas valve
8 AC power supply
9 Heating element AC
10 Gas burner
11 Connection block
12 Lightning
13 Display
14 Fan 2 (if options module is available)
15 Fan 1 (if options module is available)
16 Options module
17 DC supply oven (if options module is available)
18 DCsupply options module
19 CI-Bus connection
20 DC supply cable
21 12 V terminal housing (front view)
• AMP/TE Tyco: 180906
• CS Colombo: 63N025
22 DC supply cable electronics
23 DC supply cable heating element
24 internal DC supply, max. 1 A (options module, oven, fan)
