Installation

4.9.4 D+ and solar connection (only

for AES models)

D+ signal connection

In >Automatic Mode< the AES electronic

system automatically selects the most efficient

energy supply. In automatic mode the electro-

nic system uses the D+ signal (dynamo +) of

the alternator to detect 12V DC. 12V DC ope-

ration is selected only while the engine is run-

ning in order to prevent battery discharge.

S+ signal connection:

12V DC energy can be optionally achieved by

mounting solar equipment to the vehicle. The

solar power equipment must be provided with

a solar charging controller with AES output

(adequate charging controllers available in

selected stores). The "S+ connection (Solar +)

must be connected to the respective terminal

of the solar charging controller (AES output).

The electronic system uses the S+ signal of

the solar charging controller to detect solar

12V DC.

Cable cross-sectional areas:

There are no particularly high current flows via

the D+ and S+ connection; therefore no parti-

cularly large cross-section is required for these

connections (approx. 1mm² is sufficient).
