Dometic RML8 Series Installation Manual

27
Fan (optional) RM(S) 8xx1, RM(S) 8xx5 :
Fig. 46
1
For MES and AES it is compulsory to provide
a permanent 12V DC supply at the terminals
C/D (permanent voltage supply for functional
electronics
= 12V OUT / 12 V power supply for optional connections
= Ground connection heating element 12VDC
= Positive connection, heating element 12VDC
= Ground connection electronics 12VDC
= Positive connection electonics 12VDC
1
A
B
C
D
289 0318-00_EN_RMx8xxx-Installation_N1-1.qxp 20.07.2012 10:44 Seite 27
