EN
RML9xxx Installing the refrigerator
21
6.4 Installing the ventilation grille
➤ Ensure the installation frame is water resistant (fig. a, page 7).
➤ Insert the installation frame and screw it down tightly (fig. b , page 7).
➤ Fit the ventilation grille (fig. c, page 7).
➤ Insert the slider and lock the ventilation grille with it (fig. c, page 7).
6.5 Install the roof vent
➤ Ensure the installation frame is water resistant (fig. e, page 8).
➤ Insert the installation frame and screw it down tightly (fig. e , page 8).
➤ Insert the hood and screw it down tightly (fig. f, page 8).
No. in
fig. 0, page 6
Description
1 Installation frame
2 Ventilation grille
3 Winter cover
4Slider
No. in
fig. d, page 7
Description
1 Installation frame
2 Hood
