Installing the refrigerator RML9xxx
22
6.6 Install the flue duct
I
The flue duct is installed at the factory. Follow these steps when you have removed
the flue duct and want to reinstall it (fig. g, page 8):
➤ Place the T-piece (1) on the adaptor (2) and the flue pipe (3).
➤ Direct the T-piece at an angle of 45° towards the rear wall.
➤ Attach the T-piece, adaptor and flue pipe with a screw (4).
6.7 Securing the refrigerator
!
I
Proceed as follows (fig. h , page 8):
➤ Move the refrigerator into its final location.
➤ Fasten the four screws (1) through the four plastic washers in the sides of the
refrigerator, and further into the wall.
➤ Put the caps (2) onto the screw heads.
NOTE
Do not install an additional flue stack, as this leads to poor performance
and increases the power consumption of the refrigerator.
CAUTION!
Only drill through the receptacles provided, otherwise foamed
components, including cables, can be damaged.
NOTE
Attach the side walls or the attached strips so that the screws are tight,
even when under increased loads (while driving).
