RUC5208X, RUC6408X, RUC8408X Installing the refrigerator
19
7.4 Installing the ventilation grille
➤ Make a cut out in the wall to fit an appropriate upper and lower vent system,
choose LS300 check the dimensions required for the vent. See chapter “Prepar-
ing the installation” on page 12.
➤ Ensure the installation frame is water resistant (fig. c).
No. in
fig. b
Description
1Slider
2 Ventilation grille
3 Installation frame
3
2
1
b
c
d
