RUC5208X, RUC6408X, RUC8408X Using the refrigerator
49
➤ Remove the two screws (1. in fig. K) from the latch assembly on both doors.
➤ Push the spring bolt (2. in fig. K) inwards with a small screwdriver, until the latch
assembly (fig. K 1) is released.
➤ Remove the latch assembly (3. in fig. K ) from both doors.
➤ Remove the latch blanks from the opposite side of both doors.
➤ The original freezer and refrigerator door latch assemblies swap to the opposite
door due to the spring bolt function.
➤ Relocate the door hinge bush to the opposite side.
➤ Exchange the latch assemblies and latch blanks and install each of them
on the opposite side.
3.
