6
Check the outboard engine manufacturer’s instructions carefully
for specifications regarding connection hardware. Ensure the
outboard engine manufacturer’s requirements are followed.
WARNING
The use of a transom stiffener for the top bolts on the transom side
of the jackplate-to-transom connection is recommended.
NOTICE
[
1
] Jackplate
[
3]
Rocker Switch
[
2
] Relay Wiring Harness
[
4]
Spade Terminals (Female)
Figure 4. Included parts.
The following parts are included with your SeaStar Jackplate
product. If any of these components are missing, contact your
dealer or Dometic.
