Dometic Seastar JackPlate - Table of Contents

i
INDEX
Congratulations on your purchase of a SeaStar Jackplate. You have
chosen to install one of the sleekest and most durable engine
Jackplates available. Prepare for increased performance, gains in
fuel economy and the ability to run in shallow water.
1.0 Safety Information ......................................................... 1
1.1 Before Installation .................................................... 1
1.2 During Installation ..................................................... 1
1.3 Prior to Each Use ...................................................... 2
1.4 During Use ............................................................... 2
1.5 After Use ................................................................. 2
1.6 Maintenance ............................................................ 3
1.7 Corrosion Protection .................................................. 3
1.8 Trailering and Storage ............................................... 4
1.9 Important Labels ...................................................... 4
2.0 Jackplate Installation ..................................................... 5
2.1 Parts & Tools ............................................................ 5
2.2 Mount Jackplate to Boat ........................................... 7
2.3 Install Relay Wiring Harness .................................... 10
2.4 Install Rocker Switch ............................................... 12
2.5 Mount Outboard to Jackplate ................................... 13
2.6 Clearance Checks ................................................... 14
3.0 Troubleshooting Guide .................................................. 15
4.0 Warranty ..................................................................... 17
4.1 Statement of 2-Year Limited Warranty ....................... 17
4.2 Return Goods Procedure ......................................... 18
4.3 Technical Support ................................................... 18
Introduction
Figure 1. SeaStar Jackplate.
TRANSOM SIDE OF JACKPLATE
(SHOWN EXTENDED)
ENGINE SIDE OF JACKPLATE
(SHOWN RETRACTED)
