ELECTRICAL INFORMATION
• For electrical and technical information on the machine, consult the label on the
back of the machine.
• Always connect the machine to an earthed outlet.
• Make sure that the outlet is still accessible after the machine is installed.
• Do not use extension cords or other adapter plugs with this machine. If you decide
to use an extension cord out of necessity, use a splash resistant cable suitable for
outdoor use.
• Always unplug the machine from the outlet before performing maintenance.
COMPONENTS
1. Control Panel
2. Grill Air Intake
3. Water Reservoir
4. Float (tells the machine that the water reservoir is full)
5. Air lter (behind the grill)
6. Handle
7. Grill Exhaust
8. Fastener band for the cord (only for storing the machine)
9. Outlet for the drainage hose
10. Cord
11. Plug
1
2
3
5
4
7
9
8
11
10
6
