Installation, Operation and Maintenance manual
33
DFPRE Large Dust Collectors
TABLE 4 – STANDARD FAN MOTOR SUPPLY VOLTAGE DETAILS
To comply with European standards the motor nameplate will display the
following:
3 Phase / 50 Hz (IEC 60034-30)
kW Nameplate details Range
0.75 – 3.0
230/3/50 D 220-240 D
400/3/50 Y 380-420 Y
4.0 and above
400/3/50 D 380-420 D
690/3/50 Y 660-690 Y
3 Phase / 60 Hz*
kW Nameplate details Range
0.75 – 3.0
250-280/3/60 D 250-280 D
440-480/3/60 Y 440-480 Y
4.0 and above 440-480/3/60 D 440-480 D
*Some motors will be fitted with a second nameplate displaying 60 Hz details
The details above may not apply to non-standard motors.
