DongFeng S30 - Page 106

Circuit Diagrams of Electrical Appliances
21-97
IC08F: cockpit harness--left rear door harness (10P Black) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 6200C Red SP12 6
2 6022 Brown IC06F 7 6023 Red D001E
3 6210C Green S006 8 MC623 Green yellow SG14
4 8421 Brown IC04M 9 6024 Green IC06F
5 8420 Yellow IC04M 10 6201C Brown SP11
IC09F: cockpit harness--right rear door harness (10P Black) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 6200D Red SP12 6
2 6027 Grey IC06F 7 6028 Yellow D001E
3 6210D Brown S006 8 MC624 Green yellow SG14
4 8426 Red IC04M 9 6029 Yellow IC06F
5 8425 Green IC04M 10 6201D Red SP11
IC07M: cockpit harness--main backdoor harness (10P White) (H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 2100B Green IC04M 6 MC501
Yellow
green
SG18
1 2100D Green S101 7 810C Red SP16
2 6206 Green D001E 8 5299 Grey IC30M
3 2620A Brown S100 9
4 6265 Green D001I 10 3101 Brown D310B
5 5203 Red IC03M 10 6260 Yellow D001I
IC30M: cockpit harness--instrument panel harness (2P〕(H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 5203 Red IC07M 2 5299 Grey IC07M
