Circuit Diagrams of Electrical Appliances
21-98
Cabin harness (S30)
manual transmission+manual air conditioning VIN≥038932
manual transmission+automatic air conditioning VIN≥038979
automatic transmission+manual air conditioning VIN≥037670
automatic transmission+automatic air conditioning VIN≥037670
IC04M: cockpit harness--instrument panel harness (26P Black) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 7020 White D7020 14 601 Pink IC06F
2 7021 Red D7020 15 6411 Brown IC06F
3 2320 Milk white IC07F 16 8426 Red IC09F
4 2330 Yellow IC06F 17 6401 Yellow IC06F
5 8425 Green IC09F 18 8421 Brown IC08F
6 6412 Brown IC06F 19 7026 Brown D7025
7 8420 Yellow IC08F 20 8411 Pink IC06F
8 1202 Red D1211 21 2100B Green IC07F
9 7025 Green D7025 22 6019 Red IC06F
10 8410 Grey IC06F 23 6250A Brown SP307
11 2201 Brown IC07F 24
12 6017 Yellow IC06F 25
13 2325 Red IC07F 26
IC06F: cockpit harness--left front door harness (20P Yellow) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 MC71 Green yellow G71 11 6401 Yellow IC04M
2 6029 Yellow IC09F 12 6205 Green D001I
3 6027 Grey IC09F 13 810B Brown SP16
4 6024 Green IC08F 14 2330 Yellow IC04M
5 6022 Brown IC08F 15 6201A Green SP11
6 6019 Red IC04M 16 6412 Blue IC04M
7 6017 Yellow IC04M 17 6200A Red SP12
8 601 Pink IC04M 18 6411 White IC04M
9 6250B Brown SP307 19 8410 Grey IC04M
10 6210A Red S006 20 8411 Pink IC04M
