Circuit Diagrams of Electrical Appliances
21-12
No. Capacity Function Type of fuse
F13 20A ABS pump MINI
F14 20A front fog lamp MINI
F15 10A horn MINI
F16 10A air conditioning compressor clutch MINI
F17 60A cooling fan JCASE
F18 40A igntion switch JCASE
F19 50A
cockpit central electric control box power
supply
JCASE
F20 50A
cockpit central electric control box power
supply
JCASE
F21 40A air conditioning blower JCASE
F22 30A front electric window JCASE
F23 TBD standby ATO
F24 TBD standby ATO
List of relays for the fuse box of engine compartment:
No. Function
R1 starter relay
R2 automatic gearshift lever lock
R3 front fog lamp relay
R4 horn relay
R5 air conditioning compressor relay
R6 Rear wiper relay H30
R7 front electric window
R8 air conditioning blower relay
R9 engine relay-1
R10 engine relay-2
