Circuit Diagrams of Electrical Appliances
21-104
IC07M: rear harness --cockpit harness (20P White) (S30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 810C Pink D820A 12 6206 Yellow D6260
2 13
3 2650 Green D2620A 14 2620 Brown D2620
3 2655 Brown D2625A 14 2620A Red D2630
4 15
5 310 Green D310A 16 6265 Yellow D6265
6 2320 Red D2620 17 6260A Brown S010
7 18 2625 Green D2625
8 2325 Yellow D2625 19
9 2201 Green 8017 20 2110 Green D2620
10 20 2115 Brown D2625
11
IC05M: right front door harness --instrument panel harness (20P Yellow) (S30/H30)
(Applicable to the last six digits of VIN<005834)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 810B Green IC18F 11
2 6017 Grey D6015 12 MC804 Yellow green IC18F
3 6401 Green IC18F 13 8011 Brown IC18F
4 14
5 6210 Yellow D6215 15 2335 Yellow IC18F
6 16 6412 Brown IC18F
7 6019 Grey D6015 17 6201 Green D6215
8 602 Brown D6015 18 8415 Yellow S013
9 MC55 Green yellow SG13 19 8416 Brown S014
10 6411 Yellow IC18F 20 6200 Red D6215
IC05M: right front door harness --instrument panel harness (20P Yellow) (S30/H30)
(Applicable to the last six digits of VIN≥005834)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 810B Green IC18F 11
2 6017 Grey D6015 12 MC804 Yellow green IC18F
3 6401 Green IC18F 13 8011 Brown IC18F
4 14
5 6210 Yellow D6215 15 2335 White IC18F
6 16 6412 Brown IC18F
7 6019 Yellow D6015 17 6201 Green D6215
8 602 Brown D6015 18 8415 Yellow S013
9 MC55 Green yellow SG13 19 8416 Blue S014
10 6411 Yellow IC18F 20 6200 Red D6215
