Circuit Diagrams of Electrical Appliances
21-105
IC05M: right front door harness --instrument panel harness (20P Yellow) (S30/H30)
(Applicable to the last six digits of VIN≤005834)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 810B Green IC18F 11
2 6017 Grey D6015 12 MC804 Yellow green IC18F
3 6401 Green IC18F 13 8011 Brown IC18F
4 14
5 6210 Yellow D6215 15 2335 White IC18F
6 16 6412 Brown IC18F
7 6019 Yellow D6015 17 6201 Green D6215
8 602 Brown D6015 18 8415 Yellow S013
9 MC55 Green yellow SG13 19 8416 Blue S014
10 6411 Yellow IC18F 20 6200 Red D6215
IC18F: right front door harness --rearview (8P White) (S30/H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 2335 White IC05M 5 MC804
Yellow
green
IC05M
2 1642 Yellow green SG13 6 810B Green IC05M
3 6401 Green IC05M 7 6411 Yellow IC05M
4 8011 Brown IC05M 8 6412 Brown IC05M
IC06M: left front door harness--cockpit harness (20P Yellow) (S30/H30)
(Applicable to the last six digits of VIN<005834)
Pin Conductor
No.
Colour Connection Pin Conductor
No.
Colour Connection
1 MC621A Green yellow SG16 11 6401 Green S012
2 6029 Yellow D6000 12 6205 Brown D6000
3 6027 Green D6000 13 8108 Red IC17F
4 6024 Red D6000 14 2330 Yellow IC17F
5 6022 Yellow D6000 15 6201 Green D6210
6 6019 Brown D6000 16 6412 Brown D641
7 6017 Grey D6000 17 6200 Red D6210
8 601 Pink SP19 18 6411 Yellow D641
9 6250 Red D6210 19 8410 Red S015
10 6210 Yellow D6210 20 8411 Brown S016
To Next Page
