IC06M: right front door harness --instrument panel harness (20P Yellow) (S30/H30)
(Applicable to the last six digits of VIN≥005834)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 MC621A Green yellow SG16 11 6401 Green S012
2 6029 White D6000 12 6205 Brown D6000
3 6027 Green D6000 13 8108 Red IC17F
4 6024 Red D6000 14 2330 Yellow IC17F
5 6022 Yellow D6000 15 6201 Green D6210
6 6019 Brown D6000 16 6412 Brown D641
7 6017 Grey D6000 17 6200 Red D6210
8 601 Pink SP19 18 6411 Yellow D641
9 6250 Blue D6210 19 8410 Grey S015
10 6210 Yellow D6210 20 8411 Brown S016
IC17F: left front door harness--rearview (8P White) (S30/H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 2330 Yellow IC06M 5
2 MC641 Yellow green SG16 6 810B Red IC06M
3 6402 Green S012 7 6415 Grey D641
4 8 6416 Yellow D641
IC08M: rear door harness--cockpit harness (10P Black) (S30/H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 6200 Red D6220 6
2 6022 Green D6020 7 6023 Brown D6020
3 6210 Yellow D6220 8 MC623 Yellow green D6220
4 8421 Green D8420 9 6024 Grey D6020
5 8420 Brown D8420 10 6201 Green D6220
