DongFeng S30 - Page 116

Circuit Diagrams of Electrical Appliances
21-107
IC07F: main backdoor harness --cockpit harness (10P White) (H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 2100B Green D2100 6 MC501 Yellow green S001
2 6206 Yellow SDL 7 810C Red D820A
3 2620A Red SDL 8 5299 Grey SDL
4 6265 Yellow SDL 9
5 5203 Red SDL 10 6260 Green SDL
SDL: main backdoor harness --backdoor harness branch (10P) (H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 MC501A Yellow green S001 6
2 6265 Yellow IC07F 7 5203 Red IC07F
3 6206 Yellow IC07F 8 2620A Red IC07F
4 6260 Green IC07F 9 5299 Grey IC07F
5 10
SDR: backdoor harness branch --main backdoor harness (10P) (H30)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 MC501A Yellow green S002 6
2 6265 Yellow D6265 7 5203 Red D501A
3 6206 Yellow D6260 8 2620A Red D2630
4 6260 Green D6260 9 5299 Grey D501A
5 10
