DongFeng S30 - Page 117

Electrical appliances circuit diagram
21-29
IC10F: Main back door harness-cabin harness (4P)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 8806 Black S001 3
2 8809 Green SDR 4 8808 Red SDR
SDL: Main backdoor harness-branch back door harness (10P)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 MC501A Yellow green S001 6 8808 Red IC10F
2 6265 Yellow IC07F 7 5203 Red IC07F
3 6206 Yellow IC07F 8 2620A Red IC07F
4 6260 Green IC07F 9 5299 Grey IC07F
5 8806 Black IC10F 10 8809 Green IC10F
SDL: Branch backdoor harness-main back door harness (10P)
Pin
Conductor
No.
Colour Connection Pin
Conductor
No.
Colour Connection
1 MC501A Yellow green S002 6 8808 Red D2631
2 6265 Yellow D6265 7 5203 Red D501A
3 6206 Yellow D6260 8 2620A Red D2630
4 6260 Green D6260 9 5299 Grey D501A
5 8806 Black D2631 10 8809 Green D2631
