Circuit Diagrams of Electrical Appliances
21-146
15.1 The electrical location diagram for the electric sun roofS30/H30)
The front wiring harness
Battery
The engine compartment
IP_H The instrument wiring
harness
Cabin fuse box
RF_H The ceiling wiring harness
The ignition switch
The front head light
The sky light control module
The back top light
The high shift brake light
