Circuit Diagrams of Electrical Appliances
21-14
List of fuse for the fuse box of cockpit
No. Capacity Function of fuse
F1 5A Right front position lamp, left rear position lamp
F2 5A Cab illumination
F3 5A Left front position lamp, right rear position lamp
F4 20A
radio cassette player, theftproof control box, cockpit central
control box, theftproof LED indicating lamp, password
theftproof indicating lamp, diagnose interface, combination
instrument, clock/ multi-functional screen, automatic
air-conditioning control module
F5 15A
Theftproof control box, diagnose interface, brake lamp switch,
reversing light switch, combination instrument, back-up lamp
switch ECU, ABS module, gear selector switch, mode selector
switch, multi-functional screen
F6 10A SRS unit
F7 10A Rear fog lamp
F8 30A Cigarette lighter
F9 30A Rear window heater, rearview mirror heater
F10 30A
left rear electric doors and windows, sunroof motor (motor
power), front electric rearview mirror/electric rearview mirror
adjusting control circuit
F11 5A
Front dome lamp, rear dome lamp, luggage compartment
lamp
F12 20A
Door –locked/unlocked, luggage compartment-unlocked, front
wiper automatic reset
F13 5A
radio cassette player, clock, battery charging indicator,
sunroof module
F14 20A front wiper brush, front windshield washer
F15 15A fuel pump
F16 30A right rear electric window power supply
List of relays for the fuse box of cockpit
No. Name of relay
1 left rear window relay
2 Door locking relay
3 Door unlocking relay
4 luggage compartment unlocking relay
6 front wiper relay
7 rear window defroster relay
