Circuit Diagrams of Electrical Appliances
21-15
List of pins for the fuse box of cockpit
Pin Definition
IP B_1 Connected to rear fog lamp switch
IP B_2
DVD\radio cassette player, theft proof alarm controller, combination instrument,
theftproof LED indicating lamp, diagnose interface, quartz clock \multi-functional
screen, automatic transmission control module power supply
IP B_3
Combination instrument, air conditioning control panel, multi-functional screen, radio
cassette player, quartz clock back lighting, cigar lighter, hazard warning lamp
IP B_4
IP B_5 Airbag module APC power supply
IP B_6 Cigarette lighter socket B+power supply
IP B_7
DVD\radio cassette player, battery charging alarm lamp, quartz clock and ACC power
supply of multi-functional screen
IP B_8
IP B_9 Connected brake switch, brake lamp
IP B_10
APC power supply of combination instrument, ABSAPC power supply, diagnostic unit,
automatic transmission, theftproof alarm controller, brake switch, back-up lamp
switch(reverse sensor ECU) , gear selector switch, mode selector switch
IP C_1 Right front door close+
IP C_2 Right front door open-
IP C_3 Front/rear electric window, rearview mirror adjusting power supply drive
IP C_4 ACC power supply of wiper system
IP C_5 Connected to right rearview mirror heater, defroster indicating lamp
IP C_6 Connected to right steering lamp
IP C_7 Connected to left steering lamp
IP C_8
IP D_1 Connected to igntion switch APC gear
IP D_2 Connected to position lamp switch
IP D_3 Connected to igntion switch ACC gear
IP D_4 Connected to igntion switch KK gear
IP D_5
IP D_6 Power supply ground
IP H_1 Intermittent position of rear wiper switch (H30)
IP H_2 Connected to fuse box R6 relay of cockpit
IP H_3 Connected to front washer switch
IP H_4 Key reminder input of theftproof alarm controller
IP H_5 Intermittent position of front wiper switch
IP H_6
IP H_7
IP H_8 Connected to left steering switch
IP H_9 Connected to defroster switch
IP H_10 Connected to right steering switch
IP H_11
Connected to the slightly open switch of right front door and the open door indicating
lamp of combination instrument
IP H_12 Connected to flushing switch (H30)
IP H_13 Connected to hazard warning lamp switch
IP H_14 Signal feedback of rear wiper
