Electrical appliances circuit diagram
21-33
2.1 - Location diagram for the cigarette lighter electrical appliances (S30/H30)
Front harness
Engine
compartment
fuse box
Cabin fuse box
Instrument
panel harness
Ignition switch
Instrument
panel
harness
Cigarette
lighter
