Maintenance of electrical applicances
22-64
7. The safety air bag system
7.1 Definition for the plug connectors and pins of the safety air bag control module
(1) The chart for the air bag module plug connectors
4LOOP plug connector chart
6LOOP plug connector chart
Fig. 7.1 The chart for the air bag module plug connectors
The opening direction (right)
The plug connector error-prevention code: B-E
The pin 1
The pin 25
The pin 50
The opening direction (right)
The plug connector error-prevention code: D-H
The pin 1
The pin 25
The pin 50
