Maintenance of electrical applicances
22-65
(2) The definition for the control module pins
The definition for 4LOOP/6LOOP safety air bag control module pins
Pins The definition of pins 4LOOP 6LOOP
1 The air bag at the passenger side, high × ●
2 The air bag at the passenger side, low × ●
3 The air bag at the driver side, low × ●
4 The air bag at the driver side, high × ●
5 The power supply ● ●
6 The earthing ● ●
7 The alarm light ● ●
8 × × ×
9 Line K ● ●
10 The air bag at the front of the driver, high ● ●
11 The air bag at the front of the driver, low ● ●
12 The driver belt buckle switch × ×
13 The driver safety belt pre-tensioner, high ● ●
14 The driver safety belt pre-tensioner, low ● ●
15 Flash codes switch ● ●
16 The passenger safety belt pre-tensioner, low ● ●
17 The passenger safety belt pre-tensioner, high ● ●
18 The air bag at the front of the passenger, high ● ●
19 The air bag at the front of the passenger, low ● ●
20 The collision sensor at the side of the driver, high × ●
21 The collision sensor at the side of the driver, high × ●
22
The invalidation switch for the passenger safety air
bag
× ×
23
The closing indicator light for the passenger safety
air bag
× ×
24 × × ×
25 × × ×
26 The short bar ● ●
27 The short bar ● ●
28 The short bar ● ●
29 The short bar ● ●
30 × × ×
31 The short bar ● ●
32 The short bar ● ●
33 × × ×
34 The collision output ● ●
35 The short bar ● ●
36 The short bar ● ●
37
