DongFeng S30 - Page 22

Pin
Definition
IP H_14
Rear wiper information feedback (only for hatchback)
IP H_15
Airbag trigger
IP H_16
Logic ground
RF A_1
Front/rear ceiling lamp switch ON, High-mounted brake lamp, Sunroof module
RF A_2
High-mounted brake lamp
RF A_3
Sunroof module
RF A_4
Front/rear ceiling lamp switch DOOR
RF A_5
Sunroof motor power supply
RF A_6
Front/Rear ceiling lamp
BD E_1
Right rear position lamp
BD E_2
Left rear position lamp
BD E_3
Trunk lamp
BD E_4
Rear fog lamp
BD E_5
Driver side door/left and right door unlock
BD E_6
Fuel pump
BD E_7
Driver side door/left and right door lock
BD E_8
LIN-wire
BD E_9
Left rear power window power drive
BD E_10
Trunk unlock
BD E_11
Rear window heater, left rearview mirror heater
BD E_12
Right rear power window power drive
BD I_1
Driver side door lock switch
BD I_2
BD I_3
Driver side door lock status
BD I_4
Driver side door & left/right rear door ajar switch
BD I_5
Trunk unlock switch
BD I_6
Trunk ajar switch
FR F_1
Front wiper low-speed output
FR F_2
Front wiper stop position
FR F_3
Right front position lamp
FR F_4
Left front position lamp
FR F_5
Vehicle speed signal
FR F_6
Wiper operation position
FR F_7
Engine compartment terminal box
FR F_8
Electric horn drive relay
FR G_1
Cabin fuse box battery, positive
FR G_2
Cabin fuse box battery, positive
Cabin fuse box pin list:
Pin
Definition
IP B_1
Rear fog lamp switch
IP B_2
Audio & video unit, Immobilizer system, Instrument indicator, Immobilizer LED indicator,
Diagnostic system, Clock/Multi-function display, Auto A/C control module
IP B_3
Cab lighting lamp
IP B_4
Reserved switch input
IP B_5
Airbag unit
IP B_6
Cigar lighter
IP B_7
Audio & video unit switch, Battery warning indicator, Clock etc.
IP B_8
Reserved lower side drive output
IP B_9
Brake lamp switch
IP B_10
Brake switch, Reversing switch, ABS module, Multi-function display,
Diagnostic system, Immobilizer, instrument indicator
IP C_1
Right front door lock
IP C_2
Right front door unlock
IP C_3
Front window relay
IP C_4
Wiper fuse
IP C_5
Defroster indicator lamp, right rearview heater
IP C_6
Right turn signal lamp
IP C_7
Left turn signal lamp
IP D_1
Ignition switch APC/IG1 gear
IP D_2
Position lamp switch
IP D_3
Ignition switch ACC gear
IP D_4
Ignition switch KK/IG2 gear
IP D_5
IP D_6
Power ground
IP H_1
Rear wiper intermittent switch (only for hatchback)
IP H_2
Engine compartment terminal box (R6) rear wiper relay (only for hatchback)
IP H_3
Front wiper & washer switch
IP H_4
Key reminder input
IP H_5
Front wiper intermittent switch
IP H_6
Automatic locking signal while driving
IP H_7
Truck open switch in cab (only for taxi)
IP H_8
Left turn signal lamp switch
IP H_9
Rear defroster switch
IP H_10
Right turn signal lamp switch
IP H_11
Front passenger side door ajar switch
IP H_12
Rear wiper & washer switch
IP H_13
Hazard waning lamp switch
