Sunroof
15-19
3.1.4. Disassembly of rear seat belt
Bolt (8);
Push aside the shield (9) in the “a”
direction as indicated in the figure.
Remove bolt (10).
3.1.5. Disassembly of lower apron of
center pillar
Plastic dowel (11);
Lower apron of center pillar (4a).
Attention Do not damage snap (12).
