S/N
Special
Tool No.
Special
Tool Name
Tool Photo
Number of
Complete
Sets
Applicable
Model
Tool Category Breakdown Process Tool Group Remarks
Aeolus By Applicable Assembly Aeolus
38 BF1104
Wiper arm
separator
1 Body service tool Disassembling of wiper S30
Application: for disassembling and assembling wiper assembly.
Operation Instruction:
Take down the wiper arm nut plug, remove the nut, install wiper arm separator BF1104, and
rotate hexagon socket screw to head out the wiper arm.
