S/N
Special Tool
No.
Special Tool Name Tool Photo
Number
of
Complete
Sets
Model
Tool Category
Breakdown
Process
Tool
Group
Remarks
Aeolus
By Applicable
Assembly
Aeolus
83 BF0104 Coolant filling barrel
1
Service process for
engine
Draining - filling -
exhausting of
cooling system
S30
Application: for filling coolant & exhausting.
Operation Instruction:
Remove the coolant reservoir cover, and then fasten the coolant fill
coolant reservoir. Push the T-
bar in the coolant filling barrel to the bottom to open the
coolant filling port, and fill the coolant. Ensure that the coolant level is not below the
middle position of the coolant filling barrel. Carry ou
t the exhausting for the engine cooling
system (refer to the Service Manual for information on relevant operation processes).
After the exhausting, lift up the T-
bar in the coolant filling barrel to close the coolant filling
port and then remove the coolan
t filling barrel, and finally tighten the coolant reservoir
cover.
Caution: when installing or disassembling, screw the connecting cap of the coolant
filling barrel rather than directly turn the coolant filling barrel, in order to prevent
the joint between the coolant filling barrel and the connecting cap from being
damage which may cause coolant leakage.
