DongFeng S30 - Page 34

Circuit Diagrams of Electrical Appliances
21-25
Hinge
point
Conductor
No.
Colour Model No.1 terminal
Electrical
appliance No.
No.2 terminal
Electrical
appliance No.
SG07 MC723
Yellow
green
A/D Quartz clock D723 SG07
- MC721
Yellow
green
B/C/E/F
Multi-functional
screen
D721 SG07
- MC54
Yellow
green
ALL G54 SG07
- MC041D
Yellow
green
ALL
Combination
instrument (Blue)
D004A SG07
- MC041C
Yellow
green
ALL
Combination
instrument (Blue)
D004A SG07
- MC041B
Yellow
green
ALL
Combination
instrument (Yellow)
D004B SG07
- MC041A
Yellow
green
ALL
Combination
instrument (Blue)
D004A SG07
- MC002
Green
yellow
ALL SG07 Cabin fuse box D001H
- MC031
Green
yellow
ALL SG07 Diagnostic unit D003
- MC032
Green
yellow
ALL SG07 Diagnostic unit D003
- MC232
Yellow
green
ALL SG07
Light combination
switch
D020A
- MC820
Yellow
green
ALL SG07
Theftproof
controller module
D820
SP05 260 White ALL IC03F SP05
- 260A Blue ALL SP05
Light combination
switch B
D020B
- 260B Red ALL SP05
Light combination
switch B
D020B
- 260C Yellow ALL SP05
Light combination
switch A
D020A
- 260D Red ALL SP05
Light combination
switch A
D020A
SP07 2600A Green ALL Cabin fuse box D0018 SP07
- 2600B Brown ALL SP07
Hazard warning
switch
D2300
- 2600D Green ALL SP07
Radio cassette
player A
D840A
- 2600E Blue B/C/E/F SP07
Multi-functional
screen
D721
- 2600F Red A/D/E/F SP07 IC12F
- 2600G Yellow ALL SP07
Combination
instrument (Yellow)
D0048
- 2600G Red B/C SP07 IC13F
- 2600I Blue ALL SP07 Cigarette lighter D8100
- 2600J Brown A/D SP07 Quartz clock D723
SP10 840 Yellow ALL Audio system D840A SP10
- 820A Green ALL
Hazard warming
switch
D2300 SP10
- 010D Red A/D Quartz clock D723 SP10
- 010A Grey B/C/E/F
Multi-functional
screen
D721 SP10
- 010- Yellow ALL SP10 Cabin fuse box D001B
- 010B Green ALL SP10
Combination
instrument (Blue)
D004A
- 010C Brown ALL SP10 Diagnostic unit D003
- 010E Yellow C/D/F SP10 IC22F
- 820 Yellow ALL SP10
Theftproof
controller
D820
