DongFeng S30 - Page 35

Circuit Diagrams of Electrical Appliances
21-26
Hinge
point
Conductor
No.
Colour Model No.1 terminal
Electrical
appliance No.
No.2 terminal
Electrical
appliance No.
SP14 2330 Brown ALL IC04F SP14
- 2320 Red ALL IC04F SP14
- 2310 Red ALL IC01F SP14
- 2303 Brown ALL SP14 Cabin fuse box D001C
- 2340 Blue ALL SP14
Combination
instrument (Yellow)
D004B
SP15 2345 Red ALL
Combination
instrument (Yellow)
D0048 SP15
- 2335 Brown ALL IC05F SP15
- 2304 Green ALL SP15 Cabin fuse box D001C
- 2315 Green ALL SP15 IC01F
- 2325 Yellow ALL SP15 IC04F
SP16A 810B Yellow B/C IC05F SP16A
- 810A Yellow B/C SP16A Cabin fuse box D001C
- 810C Blue B/C SP16A
Combination
instrument (Yellow)
D004B
SP20 002B Pink ALL IC01F SP20
- 002A Red ALL Cabin fuse box 00010 SP20
- 002- Yellow ALL SP20 Ignition switch D000C
SP21 003D Green B/C IC13F SP21
- 003C Green A/D/E/F IC12F SP21
- 003- Brown ALL SP21 Ignition switch D000B
- 003A Green ALL SP21 Cabin fuse box D001D
- 003B Yellow ALL SP21 IC01F
List of hinge points of instrument panel harness (S30)
Hinge
point
Conductor
No.
Colour Model No.1 terminal
Electrical
appliance No.
No.2 terminal
Electrical
appliance No.
SG06 MC160
Green
yellow
ALL
Mode selector
switch
D1603 SG06
- MC164
Green
yellow
C/D/F
Transmission shift
lock
D1604 SG06
- MC510
Green
yellow
ALL
Wiper combination
switch
D500 SG06
- MC51
Green
yellow
ALL D51 SG06
- MC230
Yellow
green
ALL
Hazard warning
switch
D2300 SG06
- MC001
Yellow
green
ALL SG06 Cabin fuse box D001D
- MC042A
Yellow
green
ALL SG06
Combination
instrument (Yellow)
D0048
- MC042B
Yellow
green
ALL SG06
Combination
instrument (Yellow)
D0048
- MC250
Yellow
green
ALL SG06
Light combination
switch
D020B
