Circuit Diagrams of Electrical Appliances
21-27
List of hinge points of instrument panel harness (S30)
(Applicable to the last six digits of VIN<008679)
SP08 012W Red C/D/F Brake switch D210A SP08
一
822 Green ALL
Theftproof
controller module
D820 SP08
一
012F Red C/D/F Brake switch D210A SP08
一
012A Red A/B/E Brake switch D210 SP08
一
012- Red ALL SP08 Cabin fuse box D0018
一
012B Green ALL SP08 IC01F
一
012C Brown ALL SP08 IC02F
一
012G Green ALL SP08 Diagnostic unit D003
一
012H Yellow C/D/F SP08
Mode selector
switch
D1603
一
042A Yellow ALL SP08
Combination
instrument (Blue)
D004A
SP09 841 Red ALL
Radio cassette
player A
D840A SP09
一
011- Red ALL SP09 Cabin fuse box D001B
一
011A Grey ALL SP09
Combination
instrument (Yellow)
D004B
一
011B Green A/D SP09
Quartz clock
D723
一
012E Yellow B/C/E/F SP09
Multi-functional
screen
D721
List of hinge points of instrument panel harness (S30)
(Applicable to the last six digits of VIN≥008679)
SP08 012W Red C/D/F Brake switch D210A SP08
一
822 Green ALL
Theftproof
controller module
D820 SP08
一
012F Red C/D/F Brake switch D210A SP08
一
012A Red A/B/E Brake switch D210 SP08
一
012- Red ALL SP08 Cabin fuse box D001B
一
012B Green ALL SP08 IC01F
一
012C Brown ALL SP08 IC02F
一
012E Yellow B/C/E/F SP08
Multi-functional
screen
D721
一
012G Green ALL SP08 Diagnostic unit D003
一
012H Yellow C/D/F SP08
Mode selector
switch
D1603
一
042A Yellow ALL SP08
Combination
instrument (Blue)
D004A
SP09 841 Red ALL
Radio cassette
player A
D840A SP09
一
011- Red ALL SP09 Cabin fuse box D001B
一
011A Grey ALL SP09
Combination
instrument (Yellow)
D004B
一
011B Green A/D SP09 Quartz clock D723
