Circuit Diagrams of Electrical Appliances
21-48
List of junction connectors
Note: the VIN code stated in the list is the the last six digits of VIN code.
Instrument panel harness (S30)
B
manual transmission+automatic
air conditioning+display screen
C
automatic
transmission+automatic air
conditioning+display screen
E
manual transmission+manual air
conditioning+display screen
F
automatic transmission+manual
air conditioning+display screen
VIN<008679
ALL Shared
IC01F: instrument panel harness--front harness (22P Brown) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 2605 Yellow D020A ALL 12 8077 Brown IC12F E/F
2 012B Green SP08 ALL 12 8077A Brown IC13F B/C
3 2201 Brown IC04F ALL 13 5011 Yellow D500 ALL
4 2310 Red SP14 ALL 14 7031 Yellow D004B ALL
5 1330 Green D004A ALL 15 1560 Grey D004A ALL
5 1330A Green D003 ALL 16 003B Yellow SP21 ALL
6 1392 Brown D004A ALL 17 2641 Red D020A ALL
7 4001 Red D004A ALL 18 1368 Grey D721 B/C/E/F
8 2315 Green SP15 ALL 19 8081 Yellow IC12F E/F
9 8080 Grey IC12F E/F 19 8081A Yellow IC13F B/C
9 8080A Grey IC13F B/C 20 4121 Red D004B ALL
10 5014 Red D500 ALL 21 8001 Brown IC12F E/F
11 002B Pink SP20 ALL 21 8001A Brown IC13F B/C
22 1011 Green D000B B/E
22 1610 Green D000B C/F
